Nocturn Industries | Manticore-R Night Vision Binocular

Nocturn Industries | Manticore-R Night Vision Binocular

The Ultralight Articulating Night Vision Binocular - Full Control Ruggedized (UANVB-FCR) “Manticore-Ruggedized” is a articulating binocular housing made of high strength aerospace grade 7075-T6 aluminum with a full suite of onboard digital controls. Using advanced multi-axis CNC machining an ultra lightweight and robust design is achieved, including an optimal single piece pod geometry. This binocular includes features such as digital manual gain control, individual pod stow shutoff, IPD stops, user adjustable pod tension, IR-illuminator & indicator, and low battery indicator. The device is powered on-board by a single CR123A for a continuous runtime of ~25 hours.





Features:

  • 7075-T6 aluminum construction
  • Manual gain control
  • Toolless IPD stops included
  • External power port (LEMO 00B)
  • User adjustable pod tension
  • 26+ hour battery life (CR123A)
  • IR illuminator
  • Low battery indicator
  • Individual pod on/off when articulated
  • IP68+ and MIL-STD-810H rated
  • Lifetime repair or replacement warranty (on housing)



Due to constant rotating inventory, not all intensifier tubes are listed. Please contact us if you don't see tubes with the specs you need

Only Carson/Noctis optics on our build unless otherwise specified

Colors may vary in photos but tubes are all the same color

What's Included

  • Nocturn UANVB-FCR Manticore-Ruggedized Device w/ L3 Unfilmed 24UM
  • L3 Spec Sheets
  • Hard Carry Case
  • AA Batteries (2)

Specifications

  • Material: 7075-T6 aluminum
  • Finish: Mil Standard Type III class II hard anodize
  • Device Weight: 17.07 oz - 1.06 lbs. - 484 g
  • FOCUS RANGE: 9.8” TO INFINITY
  • OPERATION TIME: APPROXIMATELY 26+ HOURS
  • MAGNIFICATION: (1X) ONE POWER
  • FIELD OF VIEW: 40 DEGREES
  • DIOPTER ADJUSTMENT: -6 TO +2
  • EYE RELIEF: 25MM
  • WATER RESISTANCE: SUBMERSIBLE TO 66 FT 2 HRS
  • INTENSIFIER TUBES: COMPATIBLE WITH MX-10160/11769 OPTICS: COMPATIBLE WITH PVS-14 EYEPIECE AND OBJECTIVE
Regular price $2,599.00 USD
Regular price Sale price $2,599.00 USD
Sale Sold out
Shipping calculated at checkout.
View full details
