QDEF // 640 THERMAL MONOCULAR
NOCPIX
MICRO2-H25
The next chapter in a proven thermal platform
The NOCPIX MICRO2-H25 builds on the RH25 platform with a second-generation 640 × 512 thermal sensor, a larger circular AMOLED display, and expanded clip-on capability.
Run it handheld, helmet-mounted, in front of a compatible day optic, or as a standalone thermal sight. A 1× base magnification and familiar field of view keep the platform versatile, while updated controls and power management add capability across all four modes.
01 // SENSOR & DISPLAY
Familiar view, upgraded image
Second-generation detector
A 640 × 512 sensor with 15 mK NETD sensitivity and 20% higher detector responsivity than the RH25 V2 captures subtle thermal differences.
Circular AMOLED display
A 1.03-inch, 2560 × 2560 display provides a larger viewing interface with nearly 4.2 times the display pixels of the RH25 V2.
FastEngine architecture
A 60 Hz refresh rate keeps image updates smooth, with a listed 21% latency reduction compared with the RH25 V2.
Familiar viewing format
Retains 1× base magnification and a 17.5° × 13.1° field of view, with smooth digital zoom up to 4×.
02 // FOUR OPERATING MODES
Choose how you run it
Helmet-mounted
Use as a hands-free thermal monocular, pair with night vision in a dual-band setup, or combine two compatible H25 units for thermal binocular viewing.
Handheld
Scan property, observe wildlife, and locate heat signatures using the 1× base view and adjustable digital magnification.
Clip-on
Add thermal capability in front of a compatible day optic with 1–10× magnification support and three independent clip-on zero profiles.
Standalone sight
Access customizable reticles, adjustable reticle brightness, app-based zeroing, and Picture-in-Picture in a dedicated thermal sight configuration.
03 // HELMET & DUAL-BAND USE
Thermal with night vision in mind
NV Highlight reduces low-temperature background clutter, while NV Outline presents heat signatures as outlines. These dedicated viewing modes simplify the thermal image for use alongside night vision.
For compatible two-unit thermal binocular setups, Dual-Link lets a single master unit control menus, palettes, image settings, and zoom. The revised housing provides additional clearance for positioning the devices.
Automatic flip-to-standby places the unit in standby when flipped out of its operating position.
04 // CONTROLS, RECORDING & POWER
Control the view, capture the night
The included wireless remote brings recording, brightness, and menu controls within reach. Its scroll wheel handles digital magnification and menu navigation.
Onboard recording, Nocpix app connectivity, and 5 GHz Wi-Fi support capturing, accessing, and transferring footage. USB-C provides audio/video connectivity.
A replaceable 18650 battery provides a listed 6.5 hours of standard runtime, extending to up to 9 hours in Power-Saving Mode. True Sleep reduces standby power consumption.
BATTERY RUNTIME
Runtime varies with operating mode, settings, temperature, and battery condition.
05 // TECHNICAL SPECIFICATIONS
The details
- Model
- NOCPIX MICRO2-H25
- Thermal sensor
- 640 × 512, second generation
- NETD
- 15 mK
- Pixel pitch
- 12 µm
- Objective lens
- 25 mm
- Field of view
- 17.5° × 13.1°
- Refresh rate
- 60 Hz
- Display
- 1.03-inch circular AMOLED, 2560 × 2560
- Base magnification
- 1×
- Digital zoom
- 1–4×
- Supported day-optic magnification
- 1–10× in clip-on mode
- Eye relief
- 45 mm
- Clip-on zero profiles
- 3
- Battery
- Replaceable 18650
- Listed runtime
- 6.5 hours standard / up to 9 hours in Power-Saving Mode
- Housing
- Magnesium
- Ingress protection
- IP67
- Dimensions (L × W × H)
- 4.02 × 2.52 × 2.01 inches
- Listed weight
- 11.7 oz
06 // RH25 V2 VS MICRO2-H25
What changes with the H25?
The H25 carries forward the RH25 V2's four operating modes and familiar viewing format. The main upgrades are the detector, display, clip-on support, controls, and power management.
| Feature | RH25 V2 | MICRO2-H25 |
|---|---|---|
| Thermal sensor | 640 × 480 | 640 × 512 |
| Detector responsivity | Baseline | 20% higher |
| NETD sensitivity | 15 mK | 15 mK |
| Field of view | 17.5° × 13.1° | 17.5° × 13.1° |
| Display | 0.71-inch rectangular 1440 × 1080 |
1.03-inch circular AMOLED 2560 × 2560 |
| Digital zoom | 1–4× | 1–4× |
| Day-optic magnification support | Up to 6× | Up to 10× |
| Clip-on zero profiles | 1 | 3 |
| Refresh rate | 60 Hz | 60 Hz |
| Shutter pause | 0.3 seconds | 0.3 seconds |
| Listed runtime | 6.5 hours standard |
6.5 hours standard Up to 9 hours in Power-Saving Mode |
| Length | 4.52 inches | 4.02 inches |
| Listed weight | 11.3 oz | 11.7 oz |
THE UPGRADE IN PERSPECTIVE
The H25 adds approximately 6.7% more sensor pixels and nearly 4.2 times the display pixels in a housing approximately 11% shorter than the RH25 V2. Listed weight increases by 0.4 oz.
Field of view, digital zoom range, refresh rate, and shutter-pause duration remain unchanged.
